For targeted illumination in low mounting height areas

The BLD110 series Luminaire provides uniform crisp, white light and is suitable for lower mounting heights, confined spaces, tunnels, or utility rooms. Using four high power, high brightness LED arrays, this fixture can deliver similar light levels up to 100 watt incandescent. Compared with conventional lighting, LED Lighting consume up to 85% less energy and typically last as long as 50,000 hours or more.

Explosive gas atmosphere: Zone 1 and Zone 2;

Combustible dust environment: Zone 20, Zone 21, and Zone 22;

Explosive gas atmosphere of IIA, IIB and IIC; T1-6;



Features:

Energy-efficient: compared with conventional lighting, LED consumes up to 85% less energy.

Long life: last to 50,000h rated life or more, 50 times of incandescent bulbs, 8 times of fluorescent lamps.

High light efficiency: dedicated honeycomb mirror enhance bigger lighting area, uniform illumination.

Wide voltage range: AC220V type can operate within 170-260V range, best performance in 220-240V range.

Multi-protection: constant current with short-circuit and overvoltage protection.

Good EMC: excellent electromagnetic compatibility and anti-interference.

SMT technology: surface mounting technology keeps low working temperature of LED chip.

Optimized heat sink: aluminum housing with air diversion structure removes heat from the LEDs and driver to ensure longer life.

Dual-chamber structure: independent chambers for light source, driver and wiring ensure higher safety for ex-proof protection.

Standard material: copper-free Aluminum housing, surface with epoxy powder coating, tempered glass and stainless steel external hardware.

Improved safety: rabbet screw, sealed bonding surfaces, highly Ex-proof performance.

Easy maintenance: independent chambers for light source, power supply and wiring, modular design for easy to repair.



Explosive gas atmosphere: Zone 1 and Zone 2;

Combustible dust environment: Zone 20, Zone 21, and Zone 22;

Explosive gas atmosphere of IIA, IIB and IIC; T1-6;

Applicable height: 1.8-3.0m

Installation Distance:3.0-5.0m

Widely used in harsh and hazardous environments and industries of Petroleum Industry, Petrochemical Industry, Shipping Industry, Mining Industry, Military Industry, Metallurgical Industry, Power Generation Industry, Power Transmission Industry, Railway Industry, Public Security and Fire Fighting, etc.

Standards

IEC60079-0,IEC60079-1, EN60079-0, EN60079-1, IEC60079-31

Ex-mark

ExdⅡCT6 Gb/ExtⅢBT85℃ Db

Rated Voltage

AC/DC 220V/110V/10-30V 50/60Hz

Rated Wattage

8W

16W

Luminous Flux

800Lm

1600Lm

Color Temperature

5000-5500K(3000K available)

IP Grade

IP66

Corrosion-proof Grade

WF2

Cable Entry

G1/2″ in general, suitable for cables of Φ6mm~Φ10mm

Terminals

wires≤1.5mm²

Installation

Ceiling/Bracket/Pendant mounting

Weight

1.7Kg

Dimension

Φ150x120mm
